Parameter setting
Code Input Description
Input according to motor nameplate
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Input of current limits
C022, C023 xxx A Maximum motor current
Enter controller configuration
C000 -2- Extended code set
C005 -42- Torque control with speed limitation
Adjustment of speed controller
C011 xxxx rpm Max. max. speed
Application parameters
C019 xxxx rpm Set threshold n
act
=0
C016 xxxx rpm Reference speed n
act
n
x
C070 V
pn
At high inertias, adapt n - controller gain
Save parameter
C003 Save parameter set
