Parameter setting
Code Input Description
Input according to motor nameplate
Master and slave
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Input of current limits
Master and slave
C022, C023 xxx A Maximum motor current
Enter controller configuration
Master and slave
C000 -2- Extended code set
C005 -11- Speed control with tacho feedback
Master
C110 -1- Input selection term. 62
C111 -25- Monitor output ’M
set
’
Adjustment of speed controller
Master and slave
C011 xxxx rpm Select max. speed
C025 -2- Select adjustment at terminals 3 and 4
C029 n
act
Adjust speed
Slave
C071 9999 ms T
nn
, no I component
C025 -3- Select adjustment at terminal 6
C027 Select weighting factor for act. speed influence divided by V
pn
C070 V
pn
Adapt n-controller gain
Master and slave
C054 Check current division between master and slave.
Application parameters
Master
C019 xxxx rpm Set threshold n
act
=0
Save parameter
Master and slave
C003 Save parameter set
