Selection aid
15-12
48XX/49XXSHB0399
Parameter setting
Code Input Description
Input according to motor nameplate
C083 xxx A Rated field current
C084 xxx ms Armature-time constant
C088 xxx A Rated motor current
C090 xxx V Rated motor voltage
Freely assignable analog inputs
C145 -4- Input selection term. 8
C146 -15- Arithmetic block2 input 1
C145 -3- Input selection term. 6
C146 -16- Arithmetic block2 input 2
C145 -10- Input selection arithmetic block output
C146 -1- Main set-value C046
C145 -9- Input selection process controller output
C146 -3- Additional set-value C049
C145 -1- Input selection term. 1.2
C146 -7- Actual process controller value
Freely assignable digital inputs
C112 -3- Input selection E3
C113 -32- Process controller evaluation
C112 -5- Input selection E5
C113 -31- Process controller I component off
Arithmetic block
C191 -4- Output = input 1 / input 2
Convert distance
@
diameter
C025 -3- Input selection term. 6
C026 Offset for distance a = -xxx mV
C027 2.000 Evaluation for diameter
Adjustment of speed controller
C011 xxxx rpm Enter max. speed
C025 -2- Select adjustment at terminals 3 and 4
C029 n
act
Adjust speed
process controller
C330 xxx % Select position set-value
C331 xxx % Evaluation of process controller output
Application parameters
C022, C023 xxx A Maximum motor current
C019 xxxx rpm Set threshold n
act
=0
C070 V
pn
At high inertias, adapt n - controller gain
C222 V
pp
Optimise process controller
Save parameter
C003 Save parameter set
