Selection aid
15-22
48XX/49XXSHB0399
- Adjustable waiting time
- Adjustable number for repetition function
- Limited program branching depending on the inputs
- Jump to the following program set
( 32 adjustable position targets
( 32 adjustable speeds
( 32 adjustable acceleration/deceleration values
( 32 adjustable number of pieces
( 32 adjustable waiting times
( Manual or program operation
( Inputs and displays via keypad and display of the basic unit
( Parameter setting and diagnostics via the serial interface LECOM-A/B of
the basic unit and the PC program LEMOC2
( Connection of BCD switches
( Connection of an absolute value encoder
( Control, parameter setting and diagnostics via InterBus or Profibus possible
(variant with fieldbus connection)
Note!
For the positioning drive explained above do not only observe the Operating
Instructions 48XX/49XX but also the Operating Instructions ”Positioning” (see
register H).
