Analog outputs (monitor outputs)
Ter minal Switch position Use Level Resolution
60 Internal ground, GND
61 Actual current value -5 V...+5 V
correspond to the
rated current of the
controller
62
A
S2
Monitor 1
Output voltage(factory setting)
-10V...10V 11 bit
1
S2
Monitor 1
Output current
-20mA...+20mA 11 bit
63
A
S1
Monitor 2
Output voltage(factory setting)
-10V...+10V 11 bit
1
S1
Monitor 2
Output current
-20mA...+20mA 11 bit
1)
For changing the factory setting of switch S4, jumper 5 to ON (actual value with
ground reference), observe the following:
- Bridge terminals 4 and 5 externally.
- Set DIP switch S4, jumper 1-4 (preselected actual value) to double tacho
voltage.
The max. possible tacho voltage is 90 V!
