Installation
4-19
48XX/49XXSHB0399
Digital inputs
Name Ter minal Use
(factory setting)
Level for activation Programming
see chapter
20 Voltage supply 15V, 100mA
CW 21 Removal of quick stop, CW rotation HIGH
CCW 22 Remove quick stop, CCW rotation HIGH
1 28 Controller enable - Ctrl. enable HIGH
2 E1 Freely assignable input
(TRIP set)
HIGH
3 E2 Freely assignable input
(TRIP reset)
HIGH
4 E3 Freely assignable input
(Inhibit additional setpoint)
HIGH
5 E4, E5 Freely assignable input
(Enable JOG values, three JOG values)
HIGH
Digital outputs
Name Ter minal Use
(factory setting)
Message Programming
see chapter
1) 2)
39 Ground of the digital inputs and outputs, external GND
40 Internal ground, GND
6 41 TRIP HIGH LOW
7 44 Ready for operation - RDY HIGH HIGH
8 45 Pulse inhibit - IMP HIGH LOW
9 A1 Freely assignable output
(n
act
<n
x
)
HIGH LOW
10 A2 Freely assignable output
(n-controller = M
max
)
LOW HIGH
11 A3 Freely assignable output
(Setpoint reached, RFG
output
=RFG
input
)
HIGH HIGH
12 A4 Freely assignable output
(n
act
=0)
HIGH LOW
13 A5 Freely assignable output
(n
act
=n
set
)
HIGH HIGH
59 Supply input of the digital outputs:
24 V external or 15 V internal
1) Message in stationary controller operation
2) Message, if the function is active
