Wiring according to EM C
Power connections
19
l EDBEMV82EV EN 3.0
Wiring of the motor filter 400 V
z Install the motor filter so that the cable length does not exceed 200 m:
– This cable does not have to be shielded.
z The cable from the motor filter to the motor is subject to the same rules as for the motor
cable.


 Note!
The connections +UG and -UG of the motor filter must be directly connected with
the connections +UG and -UG of the controller (no fuses in the connecting cable)!
Otherwise the motor filter can be destroyed.
U
V
W
U1
V1
W1
U
V
W
-UG -UG+UG +UG
M
3~
8200 vector
E82ZMxxx34B
3/PE AC 400/500 V
Fig. 6 Wiring of the motor filter 400 V
3.2.2.2 Limitation of harmonic currents
For complying with the limit values according to EN 61000-3-2 the following measures must be taken
for the 8200 vector frequency inverters. Please observe that the radio interference suppression
measures already mentioned must be taken in addition.
Essential measures for complyin g with the limit values according to EN 61000-3-2
8200 v ector
Measure
Type Mains voltage
[V]
Power
[kW]
M
e
a
s
u
r
e
E82EV551K4Cxxx
3
/
PE
0.55
C000 + N
E82EV751K4Cxxx
3
/
P
E
AC 400 V
0.75
C
0
0
0
+
N
C200 + N
C000 8200 vector with integrated RFI f ilt e r
C200 8200 vector without integrated RFI filter
+ N Mains choke is required in addition
Assignment table of mains chokes
8200 v ector
Mains choke
Type Mains voltage
[V]
Power
[kW]
Order No.
E82EV551K4Cxxx
3
/
PE
0.55
E
8
2
Z
N
3
A
1
5
0
0
H
0
0
3
E82EV751K4Cxxx
3
/
P
E
AC 400 V
0.75
E82ZN3A1500H003
