Lenze 8200 vector series User Manual

Safety information
Residual hazards, Layout of the safety instructions
7
l EDBEMV82EV EN 3.0
2.2 Residual hazards
Protection of persons
z Before working on the controller check that no voltage is applied to the power terminals, the
relay output and the pins of the FIF interface,
– because the power terminals U, V, W, +UG, -UG, BR1 and BR2 remain live for at least 3
minutes after mains switch-off.
– because the power terminals L1, L2, L3; U, V, W, +UG, -UG, BR1 and BR2 remain live when
the motor is stopped.
– because the relay outputs K11, K12, K14 can remain live when the controller is
disconnected from the mains.
z If you use the non-fail safe function “Selection of direction of rotation” via the digital signal
DCTRL1-CW/CCW (C0007 = 0 ... 13, C0410/3 ≠ 255):
– In the event of an open circuit or failure of the control voltage, the drive can change its
direction of rotation.
z If you use the function ”Flying-restart circuit” (C0142 = 2, 3) with machines with a low moment
of inertia and a minimum friction:
– After controller enable in standstill, the motor can start for a short time or change its
directionofrotationforashorttime.
z The heatsink of the controller has an operating temperature of > 80°C:
– Direct skin contact with the heatsink results in burnings.
Controller protection
z All pluggable connection terminals must only be connected or disconnected when no voltage
is applied!
z Cyclic connection and disconnection of the supply voltage can overload and destroy the
input current limitation of the controller:
– In case of cyclic mains switching over a longer period of time three minutes have to pass
between two starting operations!
Motor protection
z Depending on the controller settings, the connected motor can be overheated:
– For instance, longer DC-braking operations.
– Longer operation of self-ventilated motors at low speed.
Controller/system protection
z Drives can reach dangerous overspeeds (e.g. setting of inappropriately high field
frequencies):
– The controllers do not offer any protection against these operating conditions. For this, use
additional components.

Lenze 8200 vector series Specifications

General

Category	DC Drives
Overload capacity	150% for 60 seconds
Protection class	IP20
Mains voltage	380V to 480V AC
Control method	Vector control
Communication options	CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature, short circuit
Humidity	≤ 95% relative humidity, non-condensing
Series	8200 vector
