Technical data
Terminal description
Axis modules
4
l
55
EDS700ACBA EN 5.1
EtherCAT®
X4/X5 Labelling Description
IN EtherCAT input RJ45 socket with one LED status
display for diagnostics
OUT EtherCAT output RJ45 socket with two LED status
displays for diagnostics
i700AX045 a
X4
X5
Electrical data
Acc. to EtherCAT Technology Group (ETG)
