Commissioning
The most important codes for commissioning
T
EDK82MV222 DE/EN/FR 9.0
NOR
L
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0007

uSEr
(cont.)
E4 E3 E2 E1
41
JOG1/3 DCB TRIP set DFIN1-O
N
42
QSP DCB TRIP set DFIN1-O
N
43
CW/CC
W
QSP TRIP set DFIN1-O
N
44
UP DOWN PAR DFIN1-O
N
45
CW/CC
W
QSP PAR DFIN1-O
N
46
H/Re PAR QSP JOG1/3
47
CW/QSP CCW/QS
P
H/Re JOG1/3
48
PCTRL1
-OFF
DCB
PCTRL1
-I-OFF
DFIN1-O
N
49
PCTRL1
-OFF
JOG1/3 QSP DFIN1-O
N
50
PCTRL1
-OFF
JOG1/3
PCTRL1
-I-OFF
DFIN1-O
N
51
DCB PAR
PCTRL1
-I-OFF
DFIN1-O
N
255 Free configuration under C0410 Only display
Do not change C0007 since
settings under C0410 can be
lost
C0010
uSEr
Minimum
output
frequency
0.00 0.00
Æ14.5 Hz
{0.02
Hz}
650.00
z C0010 is not effective
with bipolar setpoint
selection (-10 V ... + 10 V)
z C0010 only limits the
analog input 1
ÆSpeed setting range 1 : 6
for Lenze geared motors:
Setting absolutely required
for operation with Lenze
geared motors.
C0011
uSEr
Maximum
output
frequency
50.00 7.50
Æ87 Hz
{0.02
Hz}
650.00
C0012
uSEr
Acceleration
time main
setpoint
5.00 0.00 {0.02
s}
1300.00 Reference: frequency change
0 Hz ... C0011
z Additional setpoint Ö
C0220
z Acceleration times can be
activated via digital
signals
Ö C0101
