Commissioning
The most important codes for commissioning
T
EDK82MV222 DE/EN/FR 9.0
NOV
L
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0148*
Motor
parameter
identification
0
0 Ready
Only when the motor is
cold!
1. Inhibit controller, wait until
drive is in standstill
2. Enter the correct motor
data under C0087, C0088,
C0089, C0090, C0091
(see motor nameplate).
3. Set C0148 = 1 by
4. Enable controller
The identification
–starts, goes off
– the motor makes a
high-pitched tone, but
does not rotate!
– takes approx. 30 s
– is completed when
is on again
5. Inhibit controller
1 Start identification
z V/f-rated frequency (C0015),
slip compensation (C0021) and
motor stator inductivity (C0092)
are calculated and saved.
z The motor stator resistance
(C0084) = total resistance of
motor cable and motor is
measured and saved
C0517*
User menu
z After mains switching or
when using the function
thecodefrom
C0517/1 will be displayed.
z In Lenze setting, the user
menu contains the most
important codes for
starting-up the control
mode ”V/f characteristic
control with linear
characteristic”
z When the password
protection is activated,
only the codes entered
under C0517 are freely
accessible.
z Enter the required code
numbers in the subcodes.
Codes, which are only
active when being used
together with an
Application-I/O, cannot be
entered!
1 Memory 1 50 C0050 Output frequency (MCTRL1-NOUT)
2 Memory 2 34 C0034 Analog setpoint selection range
3 Memory 3 7 C0007 Fixed configuration - digital input
signals
4 Memory 4 10 C0010 Minimum output frequency
5 Memory 5 11 C0011 Maximum output frequency
6 Memory 6 12 C0012 Acceleration time main setpoint
7 Memory 7 13 C0013 Deceleration time main setpoint
8 Memory 8 15 C0015 V/f rated frequency
9 Memory 9 16 C0016 U
min
boost
10 Memory 10 2 C0002 Parameter set transfer
