Commissioning
The most important codes for commissioning
EDK82MV222 DE/EN/FR 9.0
L
NOU
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0088 Rated motor
current
Æ
0.0 {0.1 A} 650.0 ÆDepending on the controller
0.0 ... 2.0 x rated output
current of the controller
C0089 Rated motor
frequency
50 10 {1 Hz} 960
C0090 Rated motor
voltage
Æ
50 {1 V} 500 Æ230 V with 230 V
controllers,
400 V with 400 V
controllers
C0091 Motor cos ϕ
Æ
0.40 {0.1} 1.0 ÆDepending on the controller
C0119

-13-
Configuration
of motor
temperature
monitoring
(PTC input) /
earth fault
detection
0
0 PTC input not
active
Earth fault
detection active
z Signal output
configuration under
C0415
z If several parameter sets
are used, the monitoring
must be separately
adjusted for each
parameter set.
z Deactivate the earth fault
detection, if it has been
activated unintentionally.
z If the earth fault detection
is active, the motor starts
after controller enable
with a delay of approx.40
ms.
1 PTC input
active,
TRIP set
2 PTC input
active,
Warning set
3 PTC input not
active
Earth fault
detection
inactive
4 PTC input
active,
TRIP set
5 PTC input
active,
Warning set
C0140* Additive
frequency
setpoint
(NSET1-NADD)
0.00 -650.00 {0.02
Hz}
650.00 z Selection via function
 of the keypad or the
parameter channel
z Is added to main setpoint
z Value is stored when
switching the mains or
removing the keypad
