Lenze E82MV551_4B - Page 127

Commissioning
The most important codes for commissioning
T
EDK82MV222 DE/EN/FR 9.0
NOT
L
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0034*

uSEr
Setpoint
selection
range
Standard–I/O
(X3/8)
-12-
Observ e the switch position
of the function module!
0
0 Unipolar voltage 0 ... 5 V / 0 ... 10
V
Current 0 ... 20 mA
1 Current 4 ... 20 mA Changing the direction of
rotation is only possible with
a digital signal.
2 Bipolar voltage -10 V ... +10 V z Minimum output
frequency (C0010) not
effective
z Individual adjustment of
offset and gain
3 Current 4 ... 20 mA open-circuit
monitored
TRIP Sd5, if I < 4 mA
Changing the direction of
rotation is only possible with
a digital signal.
C0034*

(A)
uSEr
Setpoint
selection
range
Application I/O
Observ e the jumper setting of
the function module!
1 X3/1U, X3/1I
0
0 Unipolar voltage 0 ... 5 V / 0 ... 10
V
2 X3/2U, X3/2I 1 Bipolar voltage -10 V ... +10 V Minimum output frequency
(C0010) not effective
2 Current 0 ... 20 mA
3 Current 4 ... 20 mA Changing the direction of
rotation is only possible with
a digital signal.
4 Current 4 ... 20 mA open-circuit
monitored
Changing the direction of
rotation is only possible with
a digital signal.
TRIP Sd5 if I < 4 mA
C0037 JOG1 20.00 -650.00 {0.02
Hz}
650.00
JOG = fixed setpoint
Additional fixed setpoints
Ö
C0440
C0038 JOG2 30.00 -650.00 {0.02
Hz}
650.00
C0039 JOG3 40.00 -650.00 {0.02
Hz}
650.00
C0050*
uSEr
Output
frequency
(MCTRL1-NOU
T)
-650.00 {Hz} 650.00 Only display: Output
frequency without slip
compensation
C0087 Rated motor
speed
Æ
300 {1 rpm} 16000 ÆDepending on the controller
