EDK94AZMS DE/EN/FR/ES/IT 3.0
18
M5Lieferumfang−NF Zuordnung
Scope of supply
Pos. Description
Mains filter E94AZMSxxxx
Mounting Instructions
Elements at the filter
Pos. Description
PE PE connection (for M5 ring or fork−type cable lug)
X301 Mains terminal L1 ... L3
X302 Connection cable to controller, 4−core
Mounting aid for mounting base
Guide pins for mounting base
Mounting thread for mounting base
Nameplate
Fastening at the bottom
Angle bracket for "side−by−side" mounting variant, device sizes II and III
