2 Technical data
Standards
Conformity CE Low−Voltage Directive
Approvals UR UL508, Industrial Control Equipment,
Underwriter Laboratories (File−No.
E219022)
Operating conditions
Climatic conditions
Storage IEC/EN 60721−3−1 1k3 (−25 ... +60 °C)
Transport IEC/EN 60721−3−2 2k3 (−25 ... +70 °C)
Operation IEC/EN 60721−3−3 3k3 (−10 ... +55 °C)
Site altitude 0 ... 4000 m amsl
Degree of pollution EN 61800−5−1 Pollution degree 2
Vibration resistance Germanischer Lloyd General conditions:
Accelerational stability up to 0.7 g
Degree of protection
EN 60529 IP20
NEMA 250 Protection against contact to type 1
Mounting position Vertically suspended with connecting cable at
the top
Rated data
Type
U [V] I [A] L [mH]
DU [V]
P
V
[W] m [kg]
E94AZMS0034
3/PE AC 500 V
at 50 ... 60 Hz
3.2 10 10 15 3.2
E94AZMS0094
9 3.5 10 23 5.2
E94AZMS0184
18 1.1 7.4 38 8.4
E94AZMS0314
31 0.75 7.3 48 8.8
U Rated mains voltage
I Rated mains current
L Inductance
DU Voltage drop
P
V
Power loss
m Mass
