Mechanical installation
Side−by−side mounting − device size I
3
EDK94AZMS DE/EN/FR/ES/IT 3.0
27

H1_MechINS−Fi NbMontage
Side−by−side mounting − device size I
Installation steps
How to proceed for side−by−side mounting:
1. Mount the filter on the prepared mounting plate to the left of the mounting base.
– Do not screw down completely yet!
– Grid hole pattern same as for standard mounting.
2. Pre−assemble further units.
3. Align all units.
4. Screw units tightly to the mounting plate.
