3 Mechanical installation
EDK94AZMS DE/EN/FR/ES/IT 3.0
24

H1_MechINS−Fi NbMontage
3 Mechanical installation
 Note!
The filter can be mounted in two different variants. This results in differing
mounting dimensions.
ƒ Standard mounting
– The filter is mounted below the mounting base of the basic device. The
grid hole pattern of the L−force 9400 device series can be used.
ƒ Side−by−side mounting for small control cabinet depth
– Device size I: The filter is mounted left to the basic device. The grid hole
pattern of the L−force 9400 device series can be used.
– Device sizes II and III: The filter is turned by 90° and mounted left to the
basic device. The grid hole pattern of the L−force 9400 device series
cannot be used.
