Electrical installation
Control terminals
5

107
EDKCSEX064 DE/EN/FR 6.0
Shield connection of control cables and signal cables
The plate on the front of the device serves as the mounting place (two threaded
holes M4) for the shield connection of the signal cables. The screws used may
extend into the inside of the device by up to 10 mm. For optimum contact of the
shield connection, use the wire clamps from the ECSZS000X0B shield mounting
kit.
L1 L2
L3
PE
X21
+UG
+UG +UG
-UG
-UG-UG
PE
PEPE
X22
X23
+UG
BR1
BR0
T1 T2
X6
DI1 DI2 DO1 D24
+24V GND
DO1
DI1
X6
DI2
DI3
DI4
AI+
AI-
AG
+24V
GND
S24
SO
SI1
SI2
B+
B-
+
-
=
24 VDC
+24 VDC
GND
U
F 1,6 A
3
4
+
-
=
"
"
"
"
"
"
"
0
2
1
ECSxE...
ECSxS/P/M/A...
ECSXA013
Fig. 5−6 Interconnection: Control signals with internal brake resistor
 HF−shield termination by large surface connection to functional earth (see
mounting instructions for shield mounting ECSZS000X0B)
/  Contactor relay
 Voltage supply of motor holding brake 23 ... 30 V DC, max. 1.5 A
 Safe torque off (formerly: "Safe standstill")
 Controller enable/inhibit
