Monitoring functions
Overview of monitoring functions
10
199
EDBCSXA064 EN 3.2
Possible fault responses
l Lenze setting
ü Can be set
Monitoring
OffFail−QSPWarningMessageTRIPCode
SourceDescriptionFault message
x126 CE15 Communication error of the gateway function via CAN bus at interface X14
(CAN−AUX)
l C0371 = 1: Gateway channel X14 (CAN−AUX)
l C2470: Selection of the CANaux object for L_ParRead and L_ParWrite
CANaux C2485 ü ü l
x260 Err Node
Guard
"Life Guarding Event":
The controller configured as CAN slave does not receive a "Node Guarding"
telegram with the "Node Life Time" from the CAN master.
Node
Guarding
C0384 l ü ü ü
2)
ü
Temperatures / sensors
0050 OH Device heatsink temperature > 90° C MCTRL l
0051 OH1 Temperature inside the device > 90° C MCTRL l
x053 OH3 Motor temperature > 150° C MCTRL C0583 l ü ü
x054 OH4 Heatsink temperature > C0122 MCTRL C0582 ü l ü
x055 OH5 Temperature inside the device > C0124 MCTRL C0605 ü l ü
x057 OH7 Motor temperature > C0121 MCTRL C0584 ü l ü
x058 OH8 Motor temperature via inputs T1 and T2 is too high. MCTRL C0585 ü l ü
x086 Sd6 Thermal sensor error on the motor (X7 or X8) MCTRL C0594 ü ü l
x095 FAN1 Devicefan monitoring (only for built−in units) ü l
x110 H10 Device thermal sensor error on heatsink FWM C0588 l ü
x111 H11 Device thermal sensor error in the interior of the device FWM C0588 l ü
Motor / feedback system
0011 OC1 Short circuit of motor cable MCTRL l
0012 OC2 Motor cable earth fault MCTRL l
0015 OC5 Device utilisation I x t (fix 100%) MCTRL l
0016 OC6 Motor utilisation I
2
x t (threshold C0120) MCTRL l
x017 OC7 Device utilisation I x t (clip C0123) MCTRL C0604 ü l ü
x018 OC8 Motor utilisation I
2
x t (threshold C0127) MCTRL C0606 ü l ü
x032 LP1 Motor phase failure
Note: Can only be used for asynchronous motors. Activation of the motor
phase failure detection minimises the computing time available to the
user!
MCTRL C0597 ü ü l
x081 Rel1 Open circuit monitoring of the brake relay output (X25) FWM C0602 ü ü ü l
x082 Sd2 Resolver error at X7
Note: If monitoring is switched off or in the case of "Warning", the machine
can reach very high speeds in the case of fault, which may result in the
damage of the motor and the machine that is driven!
MCTRL C0586 l ü ü
x: 0 = TRIP, 1 = message, 2 = warning, 3 = FAIL−QSP
1)
Adjustable in the DDS under Project Exceptional handling
2)
For ECSxA... only
