Monitoring functions
Overview of monitoring functions
10
200
EDBCSXA064 EN 3.2
Possible fault responses
l Lenze setting
ü Can be set
Monitoring
OffFail−QSPWarningMessageTRIPCode
SourceDescriptionFault message
x085 Sd5 Master current value encoder error on analog input X6/AI+, AI− (C0034 = 1) MCTRL C0598 ü ü l
x087 Sd7 Absolute value encoder initialisation error at X8 MCTRL l
x088 Sd8 Sin&cos signal fault at X8 MCTRL C0580 ü l
x089 PL Fault during rotor position adjustment MCTRL l
Speed
x190 nErr Speed control error (monitoring window C0576) MCTRL C0579 ü ü ü ü l
x200 NMAX Max. system speed (C0596) has been exceeded. MCTRL C0607 l ü ü
Float error
0209 float Sys−T Float error in system task (ID 0) Internal l ü ü
2)
0210 float Cycl.−T Float error in cyclic task (PLC_PRG ID 1) Internal l ü ü
2)
0211 float Task1 Float error in task 1 (ID 2)
Internal l ü ü
2)
... ... ...
0218 float Task8 Float error in task 8 (ID 9)
Time−out / overflow
0105 H05 Internal fault (memory) Internal l
x108 H08 Extension board not connected properly or not supported by program. Internal l
0201 overrun
Task1
Time−out in task 1 (ID 2)
Internal l ü ü
2)
... ... ...
0208 overrun
Task8
Time−out in task 8 (ID 9)
0219 overrun
Cycl.−T
Time−out in cyclic task (PLC_PRG, ID 1) Internal l ü ü
2)
0220 noT−Fkt
Credit
Not enough technology units available in the PLC. Internal l
0230 No program No PLC program loaded in the PLC. Internal l
0231 Unallowed
Lib
You have called the library function in the PLC program. This function is not
supported.
Internal l
x232 NoCamData Motion profiles (cam data) are not available. Internal l
x240 ovrTrans
Queue
Overflow of transmit request memory Free CAN
objects
C0608 l ü ü ü ü
x241 ovr Receive Too many receive telegrams Free CAN
objects
C0609 l ü
Parameter setting
x: 0 = TRIP, 1 = message, 2 = warning, 3 = FAIL−QSP
1)
Adjustable in the DDS under Project Exceptional handling
2)
For ECSxA... only
