System modules
DFIN_IO_DigitalFrequency (node number 21)
Inputs_DFIN
13

332
EDBCSXA064 EN 3.2
System variables
Variable Data
type
Signal
type
Address Display
code
Display
format
Notes
DFIN_nIn_v Integer Velocity %IW21.0 C0426
dec
[rpm]
Value in inc/ms
DFIN_bTPReceived_b BOOL Binary %IX21.1.2 ˘ ˘
Touch probe (TP)
received
DFIN_dnIncLastScan_p
Double
integer
Position %ID21.1 ˘ ˘
Dinc during TP and task
start
Codes
Code Possible settings IMPORTANT
No. Designation Lenze/
{Appl.}
Selection
[C0419] Enc. setup 110
Encoder selection
l Selection of encoder type
indicated on the nameplate of
the Lenze motor.
l The encoder data (C0420,
C0421, C0427) is set
automatically in accordance
with the selection.
 331
 115
 122
0 Common
110 IT512−5V
Incremental encoder with TTL
level
111 IT1024−5V
112 IT2048−5V
113 IT4096−5V
210 IS512−5V
SinCos encoder
211 IS1024−5V
212 IS2048−5V
213 IS4096−5V
307 AS64−8V
SinCos absolute value encoder
with Hiperface® interface
(single−turn)
Selections 307, 308, 309 are only
possible with operating system
7.0 or higher.
308 AS128−8V
309 AS256−8V
310 AS512−8V
311 AS1024−8V
407 AM64−8V
SinCos absolute value encoder
with Hiperface® interface
(multi−turn)
Selections 407, 408, 409 are only
possible with operating system
7.0 or higher.
408 AM128−8V
409 AM256−8V
410 AM512−8V
411 AM1024−8V
[C0420] Encoder const. 512
Number of increments of the
encoder
 331
 115
 122
1 {1 inc/rev} 8192 Sets C0419 = 0 ("common") if the
value is altered.
