System modules
DFIN_IO_DigitalFrequency (node number 21)
Inputs_DFIN
13

333
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
[C0421] Encoder volt 0
Encoder voltage
 331
 115
 122
0 5.0 V
Sets C0419 = 0 ("common") if the
value is altered.
1 5.6 V
2 6.3 V
3 6.9 V
4 7.5 V
5 8.1 V
C0426 DIS: In
Signal at DFIN input
Only display
 331
−32767 {1 rpm} 32767
[C0427] Enc. signal 0
Function of the master frequency
input signals on X8 (DFIN)
 331
 115
 122
0 2−phase
1 A: speed
B: direction
2 A or B: speed or direction
C0428 DFIN TP sel. 0
DFIN touch probe signal source
 336
 331
0 Zero pulse of position encoder (C0490) X7/X8
1 Touch probe input TP1 X6/DI1
2 Zero pulse of digital frequency input X8
C0429 TP1 delay 0
DFIN dead time compensation
TP1 (DI1)
 336
 331
−32767 {1 inc} 32767
C0431 DFIN TP Edge 0
DFIN touch probe TP1 edge
(for touch probe via digital input
X6/DI1 (C0428 = 1))
 336
0 Rising edge TP1
1 Falling edge TP1
2 Rising and falling edge TP1
3 Switched off
[C0491] X8 in/out 0
Function of X8
 331
 115
 122
0 X8 is input
1 X8 is output
