Appendix
Code table
14
415
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0855 Digital process data input words
are indicated on the AIF interface
(AIF1_IN)
Hexadecimal value is bit−coded.
Read only
259
1 AIF1 IN bits 0000 {hex} FFFF Input word 2 (bit 0 ... 15)
2 AIF1 IN bits Input word 3 (bit 0 ... 15)
C0856 Analog process data input words
are indicated decimally on the
AIF interface (AIF1_IN)
100.00% = 16384
Read only
259
1 AIF1 IN words −199.99 {0.01 %} 199.99 Input word 1
2 AIF1 IN words Input word 2
3 AIF1 IN words Input word 3
C0857 AIF1 IN phi
32 bits of phase information on
the AIF interface (AIF1_IN)
Read only
259
−2147483648 {1} 2147483647
C0858 Analog process data output
words are indicated decimally on
the AIF interface (AIF1_OUT)
100.00% = 16384
Read only
264
1 AIF1 OUT
words
−199.99 {0.01 %} 199.99 Output word 1
2 AIF1 OUT
words
Output word 2
3 AIF1 OUT
words
Output word 3
C0859 AIF1 OUT phi
32−bit phase information at the
AIF interface (AIF1_OUT)
Only display
264
−2147483648 {1} 2147483647
C0863 Digital process data input words
for CAN bus interface X4
Hexadecimal value is bit−coded.
Read only
446
0000 {hex} FFFF
1 CAN IN bits Bit 0 ... Bit15 CAN1_IN: Process data input
word 1
2 CAN IN bits Bit 16 ... Bit 31 CAN1_IN: Process data input
word 2
3 CAN IN bits Bit 0 ... Bit15 CAN2_IN: Process data input
word 1
4 CAN IN bits Bit 16 ... Bit 31 CAN2_IN: Process data input
word 2
5 CAN IN bits Bit 0 ... Bit15 CAN3_IN: Process data input
word 1
6 CAN IN bits Bit 16 ... Bit 31 CAN3_IN: Process data input
word 2
