Lenze ECS series

Appendix
Code table
14

414
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0603 MONIT CE5 3
Fault response − gateway
function monitoring (CE5)
"Timeout" when remote
parameter setting (C0370) is
activated via interface X4 (CAN)
 202
 180
0 TRIP
2 Warning
3 Off
C0604 MONIT OC7 2
Fault response − monitoring of
Ixt device utilisation.
Ixt threshold can be set under
C0123.
 205
0 TRIP
2 Warning
3 Off
C0605 MONIT OH5 2
Fault response − monitoring of
temperature inside the
controller.
Temperature threshold can be
set under C0124.
 209
0 TRIP
2 Warning
3 Off
C0606 MONIT OC8 2
Fault response − monitoring of
I
2
x t motor utilisation.
Threshold can be set under
C0120.
 214
0 TRIP
2 Warning
3 Off
C0607 MONIT NMAX 0
Fault response − maximum speed
monitoring of the machine
0 TRIP
2 Warning
3 Off
C0608 ovr. Tx−Queue 2
Fault response − transmission
memory overflow of free CAN
objects
0 TRIP
1 Message
2 Warning
3 Off
4 FAIL−QSP
C0609 ovr. Rx−Isr 0
Fault response Receive memory
overflow of free CAN objects
0 TRIP
4 FAIL−QSP
