Lenze ECS series User Manual

Appendix
Code table
14

413
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0593 MONIT CE3 3
Fault response − monitoring
CAN3_IN (no telegrams)
"CommErrCANIN3" (CE3)
 202
0 TRIP
2 Warning
3 Off
C0594 MONIT SD6 3
Fault response − monitoring
KTY sensor for the motor
temperature.
"SensorFault" (Sd6)
 223
0 TRIP
2 Warning
3 Off
C0595 MONIT CE4 3
Fault response − system bus
(CAN) monitoring "Bus−off" at X4
"BusOffState" (CE4)
 202
0 TRIP
2 Warning
3 Off
C0596 NMAX limit 5500
Maximum system speed
 227
0 {1 rpm} 16000
C0597 MONIT LP1 3
Fault response − monitoring of
motor phase failure (LP1)
When this function is activated,
the calculating time provided for
the user program is reduced!
 221
0 TRIP
2 Warning
3 Off
C0598 MONIT SD5 3
Fault response − master current
monitoring at X6 < 2 mA
"MastISourceDef"
 275
0 TRIP
2 Warning
3 Off
C0599 Limit LP1 5.0
Monitoring limit for motor phase
failure monitoring (LP1) with
regard to the current limit.
 221
0.01 {0.01 %} 10.00
C0602 MONIT REL1 3
Fault response − open circuit
monitoring of relay output X25
0 TRIP
2 Message
3 Off
4 FAIL−QSP
