Code table
14

412
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0582 MONIT OH4 2
Setting of the fault response −
monitoring of heatsink
temperature in C0122
 208
0 TRIP
2 Warning
3 Off
C0583 MONIT OH3 0
Fault response − monitoring of
motor temperature (fixed
temperature threshold).
Detection through KTY thermal
sensor via resolver input X7 or
encoder input X8.
 206
0 TRIP
2 Warning
3 Off
C0584 MONIT OH7 2
Fault response − motor
temperature monitoring
Temperature threshold can be
set under C0121.
Detection through KTY thermal
sensor via resolver input X7 or
encoder input X8.
Only effective if OH3 is switched
on under C0583.
 206
0 TRIP
2 Warning
3 Off
C0586 MONIT SD2 0
Fault response − monitoring
Resolver "ResolverFault" (Sd2)
 222
0 TRIP
2 Warning
3 Off
C0588 MONIT
H10/H11
0
Fault response − monitoring
Thermal sensors in the
controller.
H10: Sensor inside the device
H11: Heatsink sensor
 210
0 TRIP
2 Warning
3 Off
C0591 MONIT CE1 3
Fault response − monitoring
CAN1_IN (no telegrams)
"CommErrCANIN1" (CE1)
 202
0 TRIP
2 Warning
3 Off
C0592 MONIT CE2 3
Fault response − monitoring
CAN2_IN (no telegrams)
"CommErrCANIN2" (CE2)
 202
0 TRIP
2 Warning
3 Off
