Lenze ECS series User Manual

Appendix
Code table
14

417
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0869 32−bit phase information for
CAN bus interface X4
Read only
1 CAN OUT phi −2147483648 {1} 2147483647 CAN1_OUT
2 CAN OUT phi CAN2_OUT
3 CAN OUT phi CAN3_OUT
C0878 Digital input signals to DCTRL
Only display
 321
1 DigInOfDCTRL 0 1 Controller inhibit (CINH) 1
2 DigInOfDCTRL Controller inhibit (CINH) 2
3 DigInOfDCTRL TRIP−set
4 DigInOfDCTRL TRIP−RESET
C0879
1 Reset C0135
Controlword
0 No reset Reset DCTRL control word of
C0135
2 Reset AIF
Controlword
0 No reset Reset DCTRL control word of AIF
3 Reset CAN
Controlword
0 No reset Reset DCTRL control word of CAN
0 No reset
1 Reset Performs one "reset"
C0906 Analog input signals to MCTRL
Read only
1 MCTRL analog −199.99 {0.01 %} 199.99 Speed controller input
2 MCTRL analog Torque setpoint
3 MCTRL analog Lower torque limit
4 MCTRL analog Upper torque limit
5 MCTRL analog Limit of the position controller
6 MCTRL analog Speed for activating the torque
limitation
7 MCTRL analog Field weakening
8 MCTRL analog Integrator of the speed controller
9 MCTRL analog P adaptation of the position
controller
C0907 Digital input signals to MCTRL
Only display
1 MCTRL digital 0 1 Activating position controller
2 MCTRL digital Speed control or torque control
3 MCTRL digital Set quick stop (QSP)
4 MCTRL digital Loading integral−action
component of the speed
controller
C0908 MCTRL PosSet
Set phase signal
1 revolution = 65536 increments
Only display
−2147483648 {1 inc} 2147483647
