Appendix
Code table
14
418
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0909 speed limit 1
Limitation of direction of
rotation for speed setpoint
358
1 −175 ... +175 %
2 0 ... +175 %
3 −175 ... 0 %
C0910 MCTRL TP2
delay
0
MCTRL dead time compensation
TP2 (X6/DI2)
364
−32767 {1 inc} 32767 1 inc º approx. 60 ms
C0911 MCTRL TP2
sel.
0
MCTRL touch probe signal source
364
0 Zero pulse of position encoder (C0490) X7/X8
1 Touch probe input TP2 X6/DI2
C0912 MCTRL TP2
Edge
0
MCTRL touch probe TP2 edge
(for touch probe via digital input
X6/DI2 (C0911 = 1))
364
0 Rising edge TP2
1 Falling edge TP2
2 Rising and falling edge TP2
3 Switched off
C1120 Sync mode 0
Sync signal source
166
0 Off Off
1 CAN sync Sync connection via interface X4
(CAN)
170
2 Terminal sync Sync connection via terminal
X6/DI1
171
C1121 Sync cycle 2
Synchronisation cycle
166
1 {1 ms} 13
C1122 Sync phase 0.460
Synchronisation phase
167
0.000 {0.001 ms} 6.500
C1123 Sync window 0.010
Synchronisation window
169
0.000 {0.001 ms} 6.500
C1190 MPTC mode 0
Selection of PTC motor
temperature sensor
characteristic
0 Characteristic for PTC 83−110 (Lenze
standard)
1 Can be specifically set by the user
under C1191 and C1192
2 Characteristic for PTC 83−110 and 2 x
PTC150 (e.g. in MCS motors)
This selection is only available as
of operating system V 8.0. For
the corresponding motors, the
parameter is not automatically
transferred into GDC by the
motor data assistant. The
parameter has to be set later!
C1191 Selection of temperature
characteristic for PTC
1 Char.: temp 25 0 {1 °C} 255 PTC characteristic:
lower temperature T1
2 Char.: temp 150 PTC characteristic:
upper temperature T2
