Appendix
Code table
14
419
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C1192 Selection of resistance
characteristic for PTC
1 Char.: OHM 1000
{0}
0 {1 W} 30000 PTC characteristic:
resistance R1 at T1
2 Char.: OHM 2225 PTC characteristic:
resistance R2 at T2
C1810 SW ID LECOM Software identification LECOM
Only display
C1811 SW date
LECOM
Software creation date LECOM
Only display
C2100 Time slice 13
Time slice for cyclic task
6 {1 ms} 26
C2102 Task switch 0
Change−over:
System task àcycl. task (PLC)
0 Time slice No change−over
1 Time slice + end of PLC_PRG
2 Time slice + end of PLC_PRG + end of
system task
C2104 PLC Autorun 0
Automatic start of the PLC
program after mains connection
0 Off
1 On
C2106 Downl.protect 0
Write protection of PLC program
0 Inactive
1 Active
2 Reserved
C2108 PLC run/stop 0
Control PLC program
0 No function
1 Run
2 Stop
3 Reset
C2111 GDC Id 27012006132510 =
l Date (day.month.year): 27.01.2006
l Time (h:min:sec): 13:25:10
Creation date of PLC program
Read only
C2113 PLC Prog
Name
Name of PLC program
Read only
C2115 T−Fkt Credit 0 Number of technology units
C2116 CreditPinCode 0
Code for technology units if
service is required (please
consult Lenze)
0 {1} 4294967295
C2117 Full Credit 0 Service code
C2118 ParWriteChan
.
0
CAN object for L_ParRead and
L_ParWrite
(byComChannel = 10)
180
0 Unused PDO channel free for
reconfiguration
(CAN1...3_IN/CAN1...3_OUT)
1 Parameter data channel 2
