Appendix
Code table
14
421
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2353 Source for system bus node
addresses of
XCAN_IN/XCAN_OUT
(AIF interface X1)
185
1 XCAN addr sel 0 CAN node address (C2350) XCAN1_IN/OUTaddress
2 XCAN addr sel 0 CAN node address (C2350) XCAN2_IN/OUTaddress
3 XCAN addr sel 0 CAN node address (C2350) XCAN3_IN/OUTaddress
0 C2350 (auto) Automatically determined by
C2350
1 C2354 (man.) Determined by C2354
C2354 Alternative node addresses for
XCAN_IN/XCAN_OUT
(AIF interface X1)
185
1 XCAN addr. 129 1 {1} 512 XCAN1_INaddress 2
2 XCAN addr. 1 XCAN1_OUTaddress 2
3 XCAN addr. 257 XCAN2_INaddress 2
4 XCAN addr. 258 XCAN2_OUTaddress 2
5 XCAN addr. 385 XCAN3_INaddress 2
6 XCAN addr. 386 XCAN3_OUTaddress 2
C2355 Identifier for
XCAN_IN/XCAN_OUT
(AIF interface X1)
Read only
187
1 XCAN Id 1 {1} 2047 Identifier XCAN1_IN
2 XCAN Id Identifier XCAN1_OUT
3 XCAN Id Identifier XCAN2_IN
4 XCAN Id Identifier XCAN2_OUT
5 XCAN Id Identifier XCAN3_IN
6 XCAN Id Identifier XCAN3_OUT
C2356 Time settings for XCAN
(AIF interface X1)
188
1 XCAN times 0 0 {1 ms} 65000 XCAN boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 XCAN times 0
XCAN1...3_OUT cycle times:
Factor for the task time to send
process data object.
0 = event−controlled
transmission
3 XCAN times 0
4 XCAN times 0
5 XCAN times 0 Delay time for initial
transmission of the process data
objects after the NMT status
changed to "Operational"
