Appendix
Code table
14
422
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2357 Monitoring time for XCAN
process data input objects
(AIF interface X1)
Only ECSxA: When the subcodes
1 ... 4 are set, consider the task
runtime:
C2357/1...4 = Desired monitoring
time / task runtime
192
1 CE monit time 3000 1 {1 ms} 65000 XCAN1_IN monitoring time
2 CE monit time 3000 XCAN2_IN monitoring time
3 CE monit time 3000 XCAN3_IN monitoring time
4 CE monit time 3000 Bus−off
5 CE monit time 3000 AIF monitoring time (can only be
set if C2357/6 = 0)
6 CE monit time 0 Sync monitoring time (can only
be set if C2357/5 = 0)
C2359 AIF HW Set. 0
0 {1} 65535
C2364
0 Event−controlled PDO
transmission
(AIF interface X1)
0 Send PDOs when changing to
"Operational" state
1 Do not send PDOs
C2365 Enabling the second parameter
data channel and the PDO
channels
(aIF interface X1)
1 0 0 {1} 3 Enabling the second parameter
data channel
2 1 Enabling the first process data
channel
3 1 Enabling the second process data
channel
4 1 Enabling the third process data
channel
0 Deactivated
1 Activated
2 Reception activated
3 Transmission activated
C2367 Sync Rx Id 128
XCAN receive identifier of the
sync telegram(AIF interface X1)
1 {1} 2047
C2368 Sync Tx Id 128
XCAN send identifier of the sync
telegram
(AIF interface X1)
1 {1} 2047
C2369 0
XCAN Consumer Heartbeat
COB−ID
(AIF interface X1)
0 {1} 255
