Lenze ECS series User Manual

Appendix
Code table
14

423
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2370 XCAN Heartbeat time setting
(AIF interface X1)
1 0 0 {1 ms} 65535 Consumer heartbeat time
2 0 0 {1 ms} 65535 Producer heartbeat time
C2371 128
XCAN COB−ID Emergency Object
(AIF interface X1)
0 {1} 2047
C2372 0
XCAN COB−ID Emergency Object
(AIF interface X1)
0 {1} 65535 Inhibit time emergency
C2373 XCAN Sync counter
(AIF interface X1)
1 Sync Rate IN 1 1 {1} 240 XCAN1_IN
2 Sync Rate IN 1 XCAN2_IN
3 Sync Rate IN 1 XCAN3_IN
C2374 XCAN Sync counter
(AIF interface X1)
1 Sync Rate OUT 1 1 {1} 240 XCAN1_OUT
2 Sync Rate OUT 1 XCAN2_OUT
3 Sync Rate OUT 1 XCAN3_OUT
C2375 TX mode for XCANx_OUT
(AIF interface X1)
1 XCAN Tx
mode
0 Response to sync XCAN1_OUT
2 XCAN Tx
mode
0 Response to sync XCAN2_OUT
3 XCAN Tx
mode
0 Response to sync XCAN3_OUT
0 Response to sync
1 No response to sync
2 Event
3 Event, cycle C2356 superimposed
C2376 XCAN1_OUT mask
(AIF interface X1)
1 XCAN1 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN1 Mask FFFF Mask for process data output
word 2
3 XCAN1 Mask FFFF Mask for process data output
word 3
4 XCAN1 Mask FFFF Mask for process data output
word 4
