Appendix
Code table
14
424
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2377 XCAN2_OUT mask
(AIF interface X1)
1 XCAN2 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN2 Mask FFFF Mask for process data output
word 2
3 XCAN2 Mask FFFF Mask for process data output
word 3
4 XCAN2 Mask FFFF Mask for process data output
word 4
C2378 XCAN3_OUT mask
(AIF interface X1)
1 XCAN3 Mask FFFF 0000 {hex} FFFF Mask for process data output
word 1
2 XCAN3 Mask FFFF Mask for process data output
word 2
3 XCAN3 Mask FFFF Mask for process data output
word 3
4 XCAN3 Mask FFFF Mask for process data output
word 4
C2382 The XCAN monitoring is
configured if no telegrams have
been received.
(AIF interface X1)
1 XCAN Conf. CE 0 Off XCAN1_IN
2 XCAN Conf. CE 0 Off XCAN2_IN
3 XCAN Conf. CE 0 Off XCAN3_IN
4 XCAN Conf. CE 0 Off Bus−off
5 XCAN Conf. CE 0 Off Life Guarding / Heartbeat Event
6 XCAN Conf. CE 0 Off Response to sync reception
0 Off
1 Controller inhibit (CINH)
2 Quick stop (QSP)
C2450 CANa address 1
Node address for CAN bus
interface X14 (CAN−AUX)
156
458
1 {1} 63 This code is inactive if one of DIP
switches 2 ... 7 and switch 1 are
set to "ON".
C2451 CANa baud
rate
0
Baud rate for CAN bus interface
X14 (CAN−AUX)
156
0 500 kBit/s
1 250 kBit/s
2 125 kBit/s
3 50 kBit/s
4 1000 kBit/s
C2452 CANa mst 0
Configuration of master/slave
for CAN bus interface X14
(CAN−AUX)
162
0 Slave
1 Master
