Lenze ECS series User Manual

Appendix
Code table
14

425
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2453 Source for system bus node
addresses of
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
 160
1 CANa addr sel 0 CAN node address (C2450) Address CANaux1_IN/OUT
2 CANa addr sel 0 CAN node address (C2450) Address CANaux2_IN/OUT
3 CANa addr sel 0 CAN node address (C2450) Address CANaux3_IN/OUT
0 C2450 (auto) Automatically determined by
C2450
1 C2454 (man.) Determined by C2454
C2454 Alternative node addresses for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
 160
1 CANa addr. 129 1 {1} 512 CANaux1_INaddress 2
2 CANa addr. 1 CANaux1_OUTaddress 2
3 CANa addr. 257 CANaux2_INaddress 2
4 CANa addr. 258 CANaux2_OUTaddress 2
5 CANa addr. 385 CANaux3_IN address 2
6 CANa addr. 386 CANaux3_OUT address 2
C2455 Identifier for
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
Read only
 458
1 CANa Id 1 {1} 2047 Identifier CANaux1_IN
2 CANa Id Identifier CANaux1_OUT
3 CANa Id Identifier CANaux2_IN
4 CANa Id Identifier CANaux2_OUT
5 CANa Id Identifier CANaux3_IN
6 CANa Id Identifier CANaux3_OUT
C2456 CAN time settings for CAN bus
interface X14 (CAN−AUX)
 163
1 CANa times 3000 0 {1 ms} 65000 CAN−AUX boot−up time:
Delay time after mains
connection for initialisation
through the master.
2 CANa times 0
CANaux2...3_OUT cycle times:
Factor for the task time to send
process data telegram.
0 = event−controlled
transmission
3 CANa times 0
4 CANa times 20 Delay time for initial
transmission of the process data
objects 2 and 3 after the CAN bus
changed to "Operational"
C2457 Monitoring time for
CANaux1...3_IN (CAN bus
interface X14)
 202
1 CE monit time 3000 1 {1 ms} 65000 CE11 monitoring time
2 CE monit time 3000 CE12 monitoring time
3 CE monit time 3000 CE13 monitoring time
