Appendix
Code table
14
427
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2461 Detected load
CANaux_IN/CANaux_OUT (CAN
bus interface X14)
Read only
A faultless operation is only
guaranteed if the total bus load
of all connected nodes amounts
to a value £ 80 %.
179
1 Load IN/OUT 0 {1 %} 100 All sent telegrams
2 Load IN/OUT All received telegrams
3 Load IN/OUT Sent to CANaux1_OUT
4 Load IN/OUT Sent to CANaux2_OUT
5 Load IN/OUT Sent to CANaux3_OUT
6 Load IN/OUT Sent to parameter data
channel 1
7 Load IN/OUT Sent to parameter data
channel 2
8 Load IN/OUT Received from CANaux1_IN
9 Load IN/OUT Received from CANaux2_IN
10 Load IN/OUT Received from CANaux3_IN
11 Load IN/OUT Received from parameter data
channel 1
12 Load IN/OUT Received from parameter data
channel 2
C2466 Sync Response 1
CAN sync response for interface
X14 (CAN−AUX)
The value "1" should always be
set!
0 No response
1 Response
C2467 Sync Rx ID 128
CAN−AUX sync receipt ID for CAN
bus interface X14
168
1 {1} 256
C2468 Sync Tx ID 128
CAN−AUX Sync−transmission ID
for CAN bus interface X14
442
169
1 {1} 256
C2469 Sync Tx time 0
CAN−AUX sync transmission cycle
for CAN bus interface X14
A sync telegram with the
identifier of C2468 is sent with
the set cycle time.
166
163
0 {1 ms} 65000 0 = switched off
C2470 ParWrite 0
CANaux channel used by
L_ParWrite/L_ParRead
(byComChannel = 11)
180
0 Unused PDO channel free for
reconfiguration
(CANaux1...3_IN/CANaux1...3_OUT)
1 Parameter data channel 2
