Lenze ECS series User Manual

Appendix
Code table
14

428
EDBCSXA064 EN 3.2
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C2481 MONIT CE11 3
Fault response − monitoring
CANaux1_IN error
"CommErrCANauxIN1" (CE11)
 202
0 TRIP
2 Warning
3 Off
C2482 MONIT CE12 3
Fault response − monitoring
CANaux2_IN error
"CommErrCANauxIN2" (CE12)
 202
0 TRIP
2 Warning
3 Off
C2483 MONIT CE13 3
Fault response − monitoring
CANaux3_IN error
"CommErrCANauxIN3" (CE13)
 202
0 TRIP
2 Warning
3 Off
C2484 MONIT CE14 3
Fault response − "system bus
(CAN−AUX) off" monitoring at
CAN bus interface X14
"BusOffState" (CE14)
 202
0 TRIP
2 Warning
3 Off
C2485 MONIT CE15 3
Fault response − gate function
monitoring (CE15)
"Timeout" when remote
parameterisation (C0370) is
activated via interface X14
(CAN−AUX)
 202
 180
0 TRIP
2 Warning
3 Off
C2491 Process data input words
(hexadecimal) for CAN bus
interface X14
Hexadecimal value is bit−coded.
Read only
1 CANa IN bits 0 {1 hex} FFFF CANaux1_IN (bit 0 ... 15)
2 CANa IN bits CANaux1_IN (bit 16 ... 31)
3 CANa IN bits CANaux2_IN (bit 0 ... 15)
4 CANa IN bits CANaux2_IN (bit 16 ... 31)
5 CANa IN bits CANaux3_IN (bit 0 ... 15)
6 CANa IN bits CANaux3_IN (bit 16 ... 31)
