Lenze ECSEE040 - Page 145

Appendix
Code list
11

145
EDBCSXE040 EN 6.0
Parameter
C0354
Designation
CAN_IN/OUT ID offset
Data type: INTEGER_32
Index: 24221
dec
= 5E9D
hex
ID offset for calculating individual COB−IDs: COB−ID = 384 + ID offset
 98
Note:
l This code is not active if one of the switches 2 ... 7 of the DIP switch is set to "ON".
l After the setting, a reset node is required.
Setting range (min. value | unit | max. value)
0 513
Subcodes Lenze setting Information
C0354/1 32 ID offset for COB−ID CAN1_IN
C0354/2 160 ID offset for COB−ID CAN1_OUT
C0354/3 288 ID offset for COB−ID CAN2_IN
C0354/4 289 ID offset for COB−ID CAN2_OUT
C0354/5 416 ID offset for COB−ID CAN3_IN
C0354/6 417 ID offset for COB−ID CAN3_OUT
Parameter
C0355
Designation
CAN_IN/OUT identifier (COB−IDs)
Data type: INTEGER_32
Index: 24220
dec
= 5E9C
hex
Display of the CAN_IN/OUT identifiers (COB−IDs)
 99
Display range (min. value | unit | max. value)
0 2047
Subcodes Information
C0355/1 COB−ID CAN1_IN
C0355/2 COB−ID CAN1_OUT
C0355/3 COB−ID CAN2_IN
C0355/4 COB−ID CAN2_OUT
C0355/5 COB−ID CAN3_IN
C0355/6 COB−ID CAN3_OUT
