Lenze ECSEE040 - Page 147

Appendix
Code list
11

147
EDBCSXE040 EN 6.0
Parameter
C0359
Designation
CAN status
Data type: INTEGER_32
Index: 24216
dec
= 5E98
hex
Display of the system bus (CAN) operating status
 107
Display list Information
0 Operational
1 Pre−operational
2 Warning
3 Bus off
4 Stopped
Parameter
C0360
Designation
CAN PDOs/mode selection
Data type: INTEGER_32
Index: 24215
dec
= 5E97
hex
Selection of CAN PDOs/mode for the process data transfer via the system bus (CAN)
 101
Selection list (Lenze setting printed in bold) Information
0 No response event−controlled/cyclic without sync
1 CAN1_IN/OUT cyclic (sync−controlled)
Parameter
C0370
Designation
SDO gateway
Data type: INTEGER_32
Index: 24205
dec
= 5E8D
hex
Activate address gateway/remote parameterisation
l C0370 ¹ 0: All code write/read accesses are redirected to the CAN node with the CAN node address set here.
l The corresponding code is accessed via parameter data channel 1 of the target device.
l C0370 = 0: remote parameterisation is deactivated
Setting range (min. value | unit | max. value) Lenze setting
0 63 0
Parameter
C0382
Designation
CAN Node Guarding: "Node Guard Time"
Data type: INTEGER_32
Index: 24193
dec
= 5E81
hex
Setting of the time interval for the status enquiry from the master
l Only relevant if C0352 = 2.
 102
Setting range (min. value | unit | max. value) Lenze setting
0 ms 65535 0 ms
Parameter
C0383
Designation
CAN Node Guarding: "Node Life Time Factor"
Data type: INTEGER_32
Index: 24192
dec
= 5E80
hex
Factor for monitoring time "Node Life Time"
l Node Life Time = C0383 x C0382
l Only relevant if C0352 = 2.
 102
Setting range (min. value | unit | max. value) Lenze setting
0 255 0
