Appendix
Code list
11
148
EDBCSXE040 EN 6.0
Parameter
C0384
Designation
Response − CAN node guarding
Data type: INTEGER_32
Index: 24191
dec
= 5E7F
hex
Response to a "Life Guarding Event"if no node guarding telegram has been received during "Node Life Time"
(C0382 x C0383).
l When C0382 = 0 or C0383 = 0, the monitoring function is not active (no node guarding fault message is
enabled).
l Only relevant if C0352 = 2.
102
Selection list (Lenze setting printed in bold) Information
0 TRIP
1 Message
2 Warning
3 Off
Parameter
C0390
Designation
Configuration diagnostics PDO via CAN
Data type: INTEGER_32
Index: 24185
dec
= 5E79
hex
Via C0390/1 ... 8 a diagnostics PDO (8 bytes) can be parameterised, which can be sent via CAN2_OUT.
l The 8 bytes can be assigned with variables for advanced diagnostics of the mains conditions and the internal
state machine (mapping).
l In C0391 the assignment in percent (0 ... 100 %) of the 8 bytes of the PDO is shown.
Conditions for sending the diagnostics PDO:
The CAN bus is "Operational" and the cycle time for CAN2_OUT is > 0 ms (C0356/2).
Possible settings
C390/x = 0 Not assigned [0 bytes]
C390/x = 1 Voltage U
L1L2
[2 bytes]
C390/x = 2 Voltage U
L2L3
[2 bytes]
C390/x = 3 Counter of the zero crossings per second (frequency measurement of U
L1L2
) [2 bytes]
C390/x = 4 Mains synchronisation n−times outside the limits (evaluation of U
sd
and U
sq
) [1 byte]
C390/x = 5 Internal status bits [1 byte]
C390/x = 6 Transformed voltage component U
sd
[2 bytes]
C390/x = 7 Transformed voltage component U
sq
[2 bytes]
C390/x = 8 Internal error bits [2 bytes]
Subcodes Information
C0390/1
Depending on the byte size of the variables selected, it
may happen that the variables in the last subcodes do
not become effective anymore.
127
...
C0390/8
Parameter
C0391
Designation
Assignment of diagnostics PDO in percent
Data type: INTEGER_32
Index: 24184
dec
= 5E78
hex
Display of the assignment of the 8 bytes of the diagnostics PDO (CAN2_OUT) in percent
127
Display range (min. value | unit | max. value)
0 % 100
