Parameter
C0400
Designation
A/D values
Data type: INTEGER_32
Index: 24175
dec
= 5E6F
hex
Display of the A/D values
Display range (min. value | unit | max. value)
−214748 214748
Subcodes Information
C0400/1 Interior device temperature
C0400/2 Design ID of the power section
C0400/3 External low−voltage supply
C0400/4 Mains current
C0400/5 Mains voltage L2_L3
C0400/6 Mains voltage L1_L2
C0400/7 Voltage across the brake resistor
C0400/8 DC−bus voltage
Parameter
C0443
Designation
Status of digital inputs
Data type: UNSIGNED_16
Index: 24132
dec
= 5E44
hex
Bit coded display of the digital input status
Display range (min. value | unit | max. value)
0x0000 0xFFFF
Bits (read only) Information
Bit 0 X6/T1, T2 Temperature of ext. brake resistor
Bit 1 X6/DI2 Controller enable (axis modules)
Bit 2 X6/DI1 Power supply enable
Bit 3 Heatsink fan
Bit 4 Thyristor driver (LOW−active)
Bit 5
Not assigned
...
Bit 15
