Lenze ECSES Series User Manual

Commissioning
Selecting the operating mode/control structure
Speed control with setpoint via analog input
6

127
EDBCSXS064 EN 4.0
6.10.1 Speed control with setpoint via analog input
Configuration C3005 = 1000
 Note!
Use the "input assistant for motor data" of the GDC for setting the motor data
( 100).
Set the following codes:
Code Meaning Further
information
DC−bus voltage thresholds and charge relay function
C0173 = x DC−bus voltage thresholds  99
C0175 = x Charge relay function
(when using an ECS supply module: C0175 = 3)
 98
Maximum motor current
C0022 = x [A] Maximum motor current (I
max
)
Controller configuration and feedback system
C3005 = 1000 Speed control with setpoint via analog input  126
C0495 = x Feedback system  103
Speed setpoint settings
C0011 = x [rpm] Maximum speed  333
C0012 = x [s] Acceleration time
 327
C0013 = x [s] Deceleration time
C0105 = x [s] Quick stop deceleration time  338
Application parameters
C0070 = x Proportional gain (V
p
) of speed controller
 333
C0071 = x [ms] Integral−action time (T
n
) of speed controller
Save parameters
C0003 = 1 Save all parameters
