Lenze ECSES Series - Changing the Direction of Rotation

Function library
Speed (speed control)
Changing the direction of rotation
12

325
EDBCSXS064 EN 4.0
12.27.1 Changing the direction of rotation
By means of the inputs SPEED−RLQ.Cw (C7411/1) and SPEED−RLQ.CCw (C7411/2) of the
function block "Speed", two functions are carried out:
ƒ Changing the direction of rotation
ƒ Set quick stop (QSP)
 Note!
Both inputs only have an effect on the speed setpoint.
 Stop!
The speed and direction of torque have to be selected according to the
application.
Signal name Response
SPEED−RLQ.CW SPEED−RLQ.CCW Rotation Quick stop (QSP)
00None Yes
1 0 To the right No
0 1 To the left No
1 1 No change No
