Lenze ECSES Series User Manual

Monitoring functions
Configuring monitoring functions
Short circuit monitoring (OC1)
9

201
EDBCSXS064 EN 4.0
9.3.3 Short circuit monitoring (OC1)
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
011 OC1 Short circuit MCTRL_bShortCircuit_b ·
· Default setting
üSetting possible
The monitoring process is activated if a short circuit occurs in the motor phases. This can
also be caused by an interturn fault in the machine.
ƒ Monitoring can also be actuated at mains connection, if an earth fault occurs.
ƒ If monitoring is actuated, the drive controller has to be disconnected from the
mains, and the short circuit has to be eliminated.
9.3.4 Earth fault monitoring (OC2)
Fault message Monitoring function System variable
Possible response
TRIP Messag
e
Warnin
g
Off
012 OC2 Earth fault MCTRL_bEarthFault_b ·
· Default setting
üSetting possible
The ECSxS... axis module is equipped with a standard earth fault detection.
ƒ If monitoring is actuated, the drive controller has to be disconnected from the
mains, and the earth fault has to be eliminated.
Possible causes of an earth fault are:
ƒ Short circuit to frame of the machine
ƒ Short circuit of a phase to the shield
ƒ Short circuit of a phase to PE
