Configuration
Configuring MotionBus/system bus (CAN)
Individual addressing
8
174
EDBCSXS064 EN 4.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0354 Alternative node address for
CAN_IN/CAN_OUT (CAN bus
interface X4)
173
1 CAN addr. 129 1 {1} 512 Address 2 CAN1_IN
2 CAN addr. 1 Address 2 CAN1_OUT
3 CAN addr. 257 Address 2 CAN2_IN
4 CAN addr. 258 Address 2 CAN2_OUT
5 CAN addr. 385 Address 2 CAN3_IN
6 CAN addr. 386 Address 2 CAN3_OUT
Save changes with C0003 = 1.
The settings are only accepted after carrying out one of the following actions:
ƒ Renewed switch−on of the 24 V low−voltage supply
ƒ Reset node via the bus system (by the network management (NMT))
ƒ Reset node with C0358 = 1
Note!
If reset node is executed via GDC, communication will be interrupted. You
therefore have to log in again manually or find the devices connected to the
bus once again (fieldbus scan).
