Function library
AIF2Out
12

260
EDBCSXS064 EN 4.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C6155 AIF2PdoMap 0
Assignment of the 8 byte user
data of the AIF2Out function
block to the fieldbus module
 258
0 W0=Int W1=Int
Byte 1, byte 2 = AIF2Out−W0
Byte 3, byte 4 = AIF2Out−W1
Byte 5, byte 6 = AIF2Out−W2
Byte 7, byte 8 = AIF2Out−W3
1 W0 / W1=Dint
Byte 1, byte 2 = AIF2Out−W0/W1
Byte 3, byte 4 = AIF2Out−W0/W1
Byte 5, byte 6 = AIF2Out−W2
Byte 7, byte 8 = AIF2Out−W3
User data
The eight bytes of user data to the fieldbus module can be assigned with
ƒ analog signals (16 bits).
ƒ phase signals (32 bits).
The switch C6155 is used to assign the eight bytes of user data to the fieldbus module:
Value in
C6155
User data
Byte 1, 2 Byte 3, 4 Byte 5, 6 Byte 7, 8
0
AIF2Out−W0
AIF2Out−W1 AIF2Out−W2 AIF2Out−W3
16 bits (C6131/5) 16 bits (C6131/6) 16 bits (C6131/7) 16 bits (C6131/8)
1
AIF1Out−W0/W1 AIF2Out−W2 AIF2Out−W3
32 bits (C6151/2) 16 bits (C6131/7) 16 bits (C6131/8)
