Lenze ECSES Series User Manual

Function library
AIF3Out
12

265
EDBCSXS064 EN 4.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C6156 AIF3PdoMap 0
Assignment of the 8 byte user
data of the AIF3Out function
block to the fieldbus module
 263
0 W0=Int W1=Int
Byte 1, byte 2 = AIF3Out−W0
Byte 3, byte 4 = AIF3Out−W1
Byte 5, byte 6 = AIF3Out−W2
Byte 7, byte 8 = AIF3Out−W3
1 W0 / W1=Dint
Byte 1, byte 2 = AIF3Out−W0/W1
Byte 3, byte 4 = AIF3Out−W0/W1
Byte 5, byte 6 = AIF3Out−W2
Byte 7, byte 8 = AIF3Out−W3
User data
The eight bytes of user data to the fieldbus module can be assigned with
ƒ analog signals (16 bits).
ƒ phase signals (32 bits).
The switch C6156 is used to assign the eight bytes of user data to the fieldbus module:
Value in
C6156
User data
Byte 1, 2 Byte 3, 4 Byte 5, 6 Byte 7, 8
0
AIF3Out−W0
AIF3Out−W1 AIF3Out−W2 AIF3Out−W3
16 bits (C6131/9) 16 bits (C6131/10) 16 bits (C6131/11) 16 bits (C6131/12)
1
AIF3Out−W0/W1 AIF3Out−W2 AIF3Out−W3
32 bits (C6151/3) 16 bits (C6131/11) 16 bits (C6131/12)
