Mechanical installation
Mounting with thermal separation (push−through technique)
Dimensions
4

44
EDBCSXS064 EN 4.0
Dimensions of mounting cutout
 Note!
Installation with shield mounting ECSZS000X0B:
ƒ Clearance below the mounting cutout > 220 mm
³ 70 mm
³ 90 mm
a1 a1
1
0
c1
h
c1
g
g
b1
b1
d
2
ECSXA063
Fig. 4−3 Dimensions of mounting cutout
 Mounting surface
 Mounting cutout for size 
 Mounting cutout for size 
Axis module Dimensions [mm]
Type Size a1 b1 c1 d g h
ECSD004

78,5
197 75 250 M5 10,5
ECSD008
ECSD016
ECSD032
ECSD048
 121,5
ECSD064

Application software: S = Speed & Torque P = Posi & Shaft
M = Motion A = Application
