Installation
Electrical installation
Connection for the CAN bus
5
l
26
EDSMF2181IB EN 3.0
Example: Selection help
Given:
l Cable cross−section: 0.5 mm
2
(according to cable specification ^ 24)
l Number of nodes: 128
l Repeater: Lenze repeater, type 2176 (cable reduction: 30 m)
At maximum number of nodes (128), the following cable lengths/number of repeaters
must comply with:
Baud rate [kbit/s] 10 20 50 125 250 500 800 1000
Max. cable length [m] 8000 3900 1500 630 290 110 40 17
Segment cable length [m] 270 270 270 270 270 110 40 17
Number of repeaters 33 16 6 2 1 − −
