Commissioning
Configuration with internal DIP switches
7
l
58
EDBMZ9374X DE/EN/FR 4.2
7.3 Configuration with internal DIP switches
) Note!
ƒ Disconnect the 3−pin terminal board of the system bus (CAN) from
the terminal extension when you are in the operating and
programming mode. This avoids errors on the system bus.
ƒ Maintain the prescribed setting sequence to avoid errors during
configuration!
Setting sequence:
1. Settings in the programming mode
2. Settings in the operating mode (normal operation)
– Addressing of the terminal extension
– Number of terminal extensions used
– Setting the CAN bus baud rate
