Lenze EtherNet/IP E84AYCEO - C13851 | All Words from Scanner; C13852 | All Words to the Basic Device; C13853 | All Words to the Basic Device

Lenze · E84AYCEO communication module (EtherNet/IP™) · Communication Manual · DMS 3.0 EN · 10/2013 · TD17 115
13 Parameter reference
13.1 Parameters of the communication module
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C13851
C13852
C13853
Parameter | Name:
C13851 | All words from scanner
Data type: INTEGER_16
Index: 10724 = 0x29E4
Display of the I/O data words transferred from the scanner to the communication module (adapter).
In the subcodes, all I/O data words transferred from the scanner are displayed. However, only the configured I/O
data words are valid.
Display range (min. value | unit | max. value)
-32768 32767
Subcodes Info
C13851/1
...
C13851/16
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13852 | All words to the basic device
Data type: INTEGER_16
Index: 10723 = 0x29E3
Display of the I/O data words transferred from the scanner to the communication module (adapter).
In the subcodes, all I/O data words transferred from the scanner are displayed. However, only the configured I/O
data words are valid.
Display range (min. value | unit | max. value)
-32768 32767
Subcodes Info
C13852/1
...
C13852/16
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C13853 | All words to the basic device
Data type: INTEGER_16
Index: 10722 = 0x29E2
Display of the I/O data words transferred from the communication module (adapter) to the scanner.
In the subcodes, all I/O data words transferred to the scanner are displayed. However, only the configured I/O data
words are valid.
Display range (min. value | unit | max. value)
-32768 32767
Subcodes Info
C13853/1
...
C13853/16
 Read access  Write access  CINH  PLC STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
